RAC Bandplan Dec.1, 2015

http://wp.rac.ca/wp-content/uploads/files/pdf/RAC%20Bandplan%20December%201%202015.pdf

New CAARC Executive for 2015 – 2016

The Annual General Meeting was held on Wednesday Nov 18th at the Red Deer Search and Rescue. Congratulations to the members who were elected to the new executive.new exec

CAARC Executive for 2015 – 2016
Past President   Bob King VE6BLD

President– Stephen Lee VA6SGL

Vice President– Rod Lins VE6XY

Secretary– Sandy Jacobs VE6SND

Treasurer– Karen McKinney VA6LDY

Directors

  1. Brian Davies VE6CKC
  2. Garry Jacobs VE6CIA
  3. Greg McKinney VA6GMC
  4. Jeff Low VA6JL
  5. Mike Mailiot VE6MIM

 Appointments
Repeaters

Skip MacAulay VE6BGT

Emergency Coordinator
Jeff Low VA6JL
Publicity
Bob King VE6BLD
Webmaster
Bob King VE6BLD
Net Control
Bob King VE6BLD

using “bargain” coax connectors

die on incorrectly threaded so239



I bought a package of 10 SO-239 chassis connectors on eBay at a great price.  The connectors looked good, teflon insulation, gold plated pins.  However it was not possible to thread a PL-259 male connector on more than 2 or 3 turns.

I then understood why the price was so low.  I decided that the solution was to re-thread the connectors.  I looked for a die at local tool stores but no luck –  I was told that 5/8-24 was a thread used in electrical connectors but not commonly used by machinists.  Checking on Amazon it became clear that the proper die was available at reasonable cost as a “gunsmiths” die.



As soon as it arrived I tried it.  I did not have a holder for this size die so I used a “Quick-clamp” with rubber pads.  I used lots of cutting oil and took my time cutting the threads.  The result was a bare brass thread which easily took the Amphenol PL-259 connector.

I don’t know if the manufacturer in China used a 16 mm die in place of 5/8″ or if they failed to take the thickness of the nickle plating into account when cutting threads.  Whatever the reason now I have the tool to make it right!



The photos tell the story.  73 and keep on building.  Earl VA6TJ





die on correct conn after rethreading rethreaded it worksu

VE6MV granted DX award

DXCC Honor roll

Congratulations to Denny, VE6MV for achieving Honor Roll status.



Okotoks sunset

Had a great weekend with our son and daughter in law in Okotoks. Had a fantastic sunset one night. Here are a few shots. Check the Gallery for more or click the newest image on the home page to link to the Gallery.

Bob

VE6BLD



IMG_0978small

IMG_0977 Panorama small

Remote antenna tuner

Remote tuners are offered by MFJ, LDG and others.  Here is my brief review of the LDG RT-100 tuner.

I purchased the tuner new, at what I considered was a competitive price.  As you can see from the photo I am using it to tune a horizontal loop antenna close to the feed-point.  The tuner is matching a short section of low loss open wire line and not a long section of coax.  The tuner requires 12V DC at low current so I powered it from a gel cell battery and a small solar trickle charger panel (CND$14).  This remote solar power arrangement has been in operation for several months now without issue.labeled installation show all

The tuner finds a match from 80 – 10 meters on the random length loop (~130m of #10 multi-strand insulated wire, 10m high).

I have found a few issues with tuning; i.e. failing to find a good match on a band or frequency.  As per the instruction manual a tune can be “forced” by changing bands, re-tuning and then returning to the frequency you want to operate on.

The second issue noted is a de-tune with changing weather / moisture conditions.  For example rain or heavy dew on the antenna may cause the antenna to re-tune.  This does not often happen but it is inconvenient there is a re-tune cycle in the middle of a QSO.

tuner interiordownload

I experimented with different baluns and found that a 4:1 air core balun worked best for me.  This balun is very easy and inexpensive to make using parts from the hardware store.   The antenna is maintained at DC ground through the balun and tuner. (Yes, the ground wire should have been green…major fail !)



weatherproofed balun



Using the remote tuner I was able to operate on SSB effectively on multiple bands with a single wire antenna using only 100 W.  The loop antenna was found to be very quiet as a receive antenna.  On 20m a signal barely audible on a dipole was perfectly Q5 on the loop antenna.

So if your opportunities for erecting antennas are restricted my experience shows that a multi band wire antenna with a remote tuner and one feedline can be an effective way to operate HF.

Needed a place for my antenna

Needed a place for my antenna in the shop for the local UHF repeater,
works good.
Egon VE6EGN/SA3EGNuhf_antenna

Maxdroid



Maxdroid

Modification to add a digital display and continuous frequency selection to VHF/UHF Maxtrac transceivers.

By

Avinoam Albo, 4X1HF Avinoam.albo@gmail.com

December 2014


opening pic

Conversion of a Maxtrac to a transceiver with display and frequency selection

In this article I will explain how to convert the venerable Maxtrac to a rig more user friendly to radio amateurs.  The modification requires  the addition of only a few inexpensive and easily available components.  When the modification is completed you will have a rig with digital display and frequency selection enabling continuous  coverage over the whole range of frequencies  where the VCO locks.  An external programmer is no longer needed.

Disclaimer:  Carrying out the modification described requires basic electronics skills.  Any modifications are the sole responsibility of the technician. This modification will likely void type certification for commercial radio service.   This article does not make any specific claims or recommendations.

Specifications of the transceiver after this modification

  • Digital display
  • Continuous frequency selection
  • Selection of transmitter output power (2 levels or more)parts required
  • Selection using VFO or memories
  • Selection of VFO frequency steps (5K, 10K, etc.)
  • Receive PL (on/off)
  • Scanning and saving frequencies to memory (future)

Required Components

  • Maxtrac VHF or UHF
  • Arduino Nano 328 controller
  • Rotary encoder
  • LCD 08 X 02 (8 characters x 2 lines)
  • 3K, 4.7K, 8.2K, 10K resistors
  • Fine gauge insulated hookup wire such as wire wrap wire

Programming the transceiver More >

Horizontal Quad Antenna

Horizontal Quad Antenna

By:  Eli Kovo, 4X4LH (originally published in the IARC newsletter 08/2015 “HaGal” and used with permission of the author.  Translated by:  Earl, VA6TJ)

I recently came across an article in an issue of “73 Magazine” from 1978 raving about an antenna called “The German Quad” which [at that time] was used by about half the hams in Germany.   Below I summarize the main points of the article.

The first thing about this antenna is that it works without a tuner on 6 bands, from 10m to 80m and also on 2m.  I could not find confirmation that it works on 6m however I am confident that it will also transmit on that band.  Compared to a symmetrical dipole, the horizontal quad has the advantage that it can be fed anywhere, even at a point close to the shack as in illustration 1.

horizontal loop ill 1

More >
